單級中壓泵 single-stage Pump for Medium Pressure |
||||
|
||||
|
型號 Model |
公稱排量 Norminal displacement m1/r |
壓力MPa Pressure |
轉(zhuǎn)速上限 Max.speed r/min |
|
|
額定 Rated |
上限 Peak |
|||
| SFB1-D5F | 5 | 12.5 | 16 | 3000 |
| SFB1-D6F | 6 | |||
| SFB1-D8F | 8 | |||
| SFB2-D10F | 10 | 3000 | ||
| SFB2-D12F | 12 | |||
| SFB2-D16F | 16 | |||
| SFB3-D20F | 20 | 3000 | ||
| SFB3-D25F | 25 | |||
| SFB3-D32F | 32 | |||
| SFB4-D40F | 40 | 2000 | ||
| SFB4-D50F | 50 | |||
| SFB4-D63F | 63 | |||
| SFB5-D80F | 80 | 2000 | ||
| SFB5-D100F | 100 | |||
| SFB5-D125F | 125 | |||
|
雙級高壓泵 Single-stage Pump for High Pressure |
||||
|
||||
|
型號 Model |
公稱排量 Norminal displacement m1/r |
壓力MPa Pressure |
轉(zhuǎn)速上限 Max.speed r/min |
|
|
額定 Rated |
上限 Peak |
|||
| SFB1-G5F | 5 | 25 | 32 | 3000 |
| SFB1-G6F | 6 | |||
| SFB1-G8F | 8 | |||
| SFB2-G10F | 10 | 3000 | ||
| SFB2-G12F | 12 | |||
| SFB2-G16F | 16 | |||
| SFB3G20F | 20 | 3000 | ||
| SFB3-G25F | 25 | |||
| SFB3-G32F | 32 | |||
| SFB4-G40F | 40 | 3000 | ||
| SFB4-G50F | 50 | |||
| SFB4-G63F | 63 | |||
| SFB5-G80F | 80 | 3000 | ||
| SFB5-G100F | 100 | |||
| SFB5-G125F | 125 | |||
